Max grinding length×width 500×200、vertical clearance 205mm wheel 47.5×397.5、
Max weight of workpice cinclusive of magnetic chuck 200kg、Table surface length 550mm、
width200mm、maximum longitudinal travel 650、cross travel 230、
feeds:longitudinal move ment of table 0.3~25 m/min、Hydraulic feed 47mm、
Graduation of hand wheel 0.02mm、Vertical hand feed revolution 0.001、Rapid feed 600mm/min、
Grinding diameter 205φ×50.8φ、19T、3000/3600rpm、spindle motor 1.5KW/2P、Weight 1800kg
This is Ryokuta Machinery from Taiwan. We have been in used machine tools for 40 years. Our stock of 95% machines are imported from Japan and exported Taiwanese-made machines to Japan and Korea.
