AMADA TP150FX 150T Press for Sale [18200] | USED MACHINERY.BZ

HOME
Select Machine Name
Gap Frame Presses
150T Press

150T Press

Access: 5

STOCK CODE	20904045			CONTACT SELLER This product is sold by Shinmeiwa Kiko Co.,Ltd. By PHONE By EMAIL
MACHINE ID	18200
MANUFACTURER	AMADA
MODEL	TP150FX
YEAR	2021
PRICE
SPECIFICATION	◆Menu: Throttle ◆Pressure Capacity (kN): 1500 ◆Stroke Length (mm): 225 ◆Power Generation Position (mm): 6.0 ◆Strokes per Minute (min-1): 25-45 ◆Flyhole Energy (kJ): 21.5-69.6 ◆Die Height (mm): 430 ◆Slide Adjustment (mm): 100 ◆Slide Bottom Dimensions (mm): 700 * 550 ◆Bolster Dimensions (mm): 1250 * 750 ◆Bolster Thickness (mm): 160 ◆Frame Gap (mm): 390 ◆Open Back Height (mm): 810 ◆Working surface height (mm): 900 ◆Main motor (kW * P): 11 * 4 ◆Die cushion capacity (kW): 95 ◆Die cushion stroke length (mm): 80 ◆Die cushion pad surface dimensions (mm): 510 * 345 ◆Total machine height (mm): 3435 ◆Machine weight (kg): 16000 ◆Slide adjustment: Electric ◆Lubrication method: Manual grease ◆Continuously variable speed: Inverter ◆Includes die cushion ✤If there are any discrepancies between the specifications and the actual product, the actual product will take precedence.
WEIGHT	16
LINK URL	https://k-smk.co.jp/en/machines/20904045/
LOCATION	-
LOCATION DETAIL
SELLER COMPANY	Shinmeiwa Kiko Co.,Ltd

ADDRESS	3-5, Higashi Mochibukucho Yokkaichi City, Mie-pref, Mie, Japan, 510-8011
CEO NAME		CONTACT PERSON	Mr.Hashimoto / Ms.Tsuji / Ms.Matsuzaki（Chinese）/ Ms.Fujita
TEL1	81-59-361-5505	TEL2
CELLPHONE		FAX	81-59-364-8737
BUSINESS HOURS		HOLIDAY
COMPANY DESCRIPTION	New & Used Machine tool,Press, Tools
INQIRY FORM	Contact By Email	MACHINE SPECIALTY	Machine Tools,Measuring / Testing,Presses,Sheet Metal
SITE URL	https://k-smk.co.jp/en/	COMPANY TYPE	Used Machine Dealer
