WASINO MACHINE LE-19J 0.8m Lathe for Sale [17895] | USED MACHINERY.BZ

HOME
Select Machine Name
Lathes
0.8m Lathe

0.8m Lathe

Access: 52

STOCK CODE	20201047			CONTACT SELLER This product is sold by Shinmeiwa Kiko Co.,Ltd. By PHONE By EMAIL
MACHINE ID	17895
MANUFACTURER	WASINO MACHINE
MODEL	LE-19J
YEAR	1972
PRICE
SPECIFICATION	◆ Swing above bed: 460 ◆ Distance from faceplate to 185 mm: 510 ◆ Swing of front and rear feed table: 240 ◆ Maximum center distance: 800 ◆ Center height from floor: 1000 ◆ Spindle through-hole diameter: 51 ◆ Spindle hole taper: M.T. No. 6 ◆ Center taper: M.T. No. 4 ◆ Speed change: 8 stages ◆ Rotation speed: 50-1200 rpm ◆ Front and rear feed table travel distance: 280 ◆ Upper feed table travel distance: 140 ◆ Front and rear feed handle scale: 0.025 per graduation ◆ Upper feed table handle scale: 0.02 per increment ◆ Center travel distance: 150 ◆ Center taper: M.T. No. 4 ◆ Maximum carriage travel distance: 765 ◆ Feed rate: 32 types ◆ Bed length: 1850 ◆ Bed width: 400 ◆ Spindle drive: 3.7kW 4P ◆ Overall length: 2170 ◆ Overall width: 960 ◆ Overall height: 1230 ◆ Approximate weight: 1900 ✤ In the event of any discrepancies between the specifications and the actual product, the actual product will take precedence.
LINK URL	https://k-smk.co.jp/en/machines/20201047/
LOCATION	Mie
LOCATION DETAIL
SELLER COMPANY	Shinmeiwa Kiko Co.,Ltd

ADDRESS	3-5, Higashi Mochibukucho Yokkaichi City, Mie-pref, Mie, Japan, 510-8011
CEO NAME		CONTACT PERSON	Mr.Hashimoto / Ms.Tsuji / Ms.Matsuzaki（Chinese）/ Ms.Fujita
TEL1	81-59-361-5505	TEL2
CELLPHONE		FAX	81-59-364-8737
BUSINESS HOURS		HOLIDAY
COMPANY DESCRIPTION	New & Used Machine tool,Press, Tools
INQIRY FORM	Contact By Email	MACHINE SPECIALTY	Machine Tools,Measuring / Testing,Presses,Sheet Metal
SITE URL	https://k-smk.co.jp/en/	COMPANY TYPE	Used Machine Dealer
