GLEASON NO.106(NC-TYPE) NC Hypoid Gear Generator for Sale [17693] | USED MACHINERY.BZ

HOME
Select Machine Name
CNC Gear Machines
NC Hypoid Gear Generator

NC Hypoid Gear Generator

Access: 120

STOCK CODE	96			CONTACT SELLER This product is sold by Ryokuta Machinery Co., Ltd.. By PHONE By EMAIL
MACHINE ID	17693
MANUFACTURER	GLEASON
MODEL	NO.106(NC-TYPE)
YEAR
PRICE
SPECIFICATION	Mitsubishi 3軸(Mldas 64)、 Max.cone distance : 107 mm Max. pitch diameter (30° spiral angal) : 10 to 1 ratio : 215 mm, 2 to 1 ratio : 190 : mm, 1 to 1 ratio : 152 mm Max. face width: 31.7 mm, Max depth : 15.8 mm Diametral pitch, coarsest : 6.35 Mod. WORK SPINDLE Diameter of taper hole at large end: 23 mm Taper per foot : 15.5 mm Depth of taper: 152.4 mm Diameter of hole through spindle: 61.9 mm Work Head Settings Offset above center, maximum :76.2 mm Offset below center, maximum : 76.2 mm Distance from machine center to nose of spindle (maximum) : 31.7 mm machine weight 7500KG
LINK URL	https://www.ryokuta.com/en/product-series/nc-hypoid-generator
LOCATION	Taichung
LOCATION DETAIL	No. 17, Industrial 9th Rd., Tali, Taichung, Taiwan
SELLER COMPANY	Ryokuta Machinery Co., Ltd.

ADDRESS	No. 17, Industrial 9th Rd, Tali, Taichung, Taichung, Taiwan, 411
CEO NAME		CONTACT PERSON	Yu Shan Tai
TEL1	886-424918089	TEL2
CELLPHONE		FAX	886-424913639
WAREHOUSE ADDRESS1	No. 17, Industrial 9th Rd, Tali, Taichung, Taiwan
BUSINESS HOURS		HOLIDAY
COMPANY DESCRIPTION	This is Ryokuta Machinery from Taiwan. We have been in used machine tools for 40 years. Our stock of 95% machines are imported from Japan and exported Taiwanese-made machines to Japan and Korea.
INQIRY FORM	Contact By Email	MACHINE SPECIALTY	Machine Tools
SITE URL	http://www.ryokuta.com/Eng/index.asp	COMPANY TYPE	Used Machine Dealer,Repair / Overhaul
