SPECIFICATION | ◆Swing above bed: 630
◆Center distance: 2000
◆Swing above cut-off: 900
◆Swing above carriage: 400
◆Bed length: 3400
◆Bed width: 425
◆Spindle through hole diameter: 54
◆Spindle taper hole: Metric taper #60
◆Spindle nose: Short taper ASA A-1-6”
◆Spindle speed: 14 stages 18-1600 rpm (7.5kW or 11kW), 14 stages 125-1120 rpm (7.5kW), 14 stages 9-800/min (5.5kW)
◆Lead screw diameter and pitch: 40mmΦ, 6mm pitch
◆Left/right feed: 64 stages 0.062-14mm/spindle revolution
◆Front/rear feed: 64 stages 0.031-7mm/1 spindle revolution
◆Inch thread cutting: 37 steps, 56-1 teeth/25.4mm
◆Metric thread cutting: 31 steps, 0.5-28mm pitch
◆Modular thread cutting: 21 steps, 0.25-7πmm pitch
◆D.P. thread cutting: 27 steps, 56-4 teeth/25.4π
◆Motor: A.C., 3 phase, 7.5kW
◆Estimated weight: 2800
✤If there is a difference between the specifications and the actual product, the actual product will take precedence. |
|---|
