STAMA

MC726/MT

Vertical 5-Axis Machining Centre – Mill-/Turn Centre Stama MC726/MT – Milling / Turning – from billet Year 2008 Siemens Sinumerik 840D sl CNC 2-Axis NC Rotary / Tilting table with collet chuck Clamping capacity 15 ~ 80 mm diameter C-Axis 360° A-Axis 120° X 500 mm Y 380 mm Z 360 mm 42 station ATC Turning spindle 20/50KW / 4000 rpm Milling spindle 17/37 KW / 10500 rpm 2 x machines available as a machining cell or individual machines sale They are currently connected in a production line. Both machines have their own chip conveyor, but they have only one coolant tank with different coolant pumps. Under power in the factory. Both machines are well maintained and in perfect condition. Regular maintenance carried out by Stama up to 2021, since then only low utilization. ALSO AVAILABLE AS SINGLE MACHINE ! Equipped with a Promot Gantry loader and parts conveyor Linear scales Internal coolant through spindle 70 bar Renishaw measuring probe Signal lamp Chip conveyor KNOLL coolant unit Proposal reference MV-6363 / Proposal reference MV-6389

EXW
