SPECIFICATION | Travels XYZ: Spindeltaper: Spindelspeeds: Tablesize: Max. workpiece diameter 150 mm Max. Modul 2,25 Max. lenght of teeth 135 mm Min./max.nr of teeth 6 ? 400 Max. hobdiam. 64 mm RPM of the spindle 200 ? 1050 rpm Feeds longitudial 0,10 ? 1,60 mm/Rev Feeds radial 0,05 ? 0,80 mm/Rev Angle on helical gears 0 ? 80 �� Installed power 3,0 kw Weight ca. 1,5 t Incl changegears spindles and hobs |
|---|
