BLOHM

Simplex 7

size of the table : 1100 x 300 [mm] - max grinding length : 700 [mm] - max grinding width : 350 [mm] - distance table / spindle axis : 575 [mm] - transversal : 300 [mm] - hydraulic longitudinal : 570 [mm] - transversal automatic feeds : 2-65 [mm] - longitudinal traverse speed : 2-30 [m/min.] - spindle speed : 1400/2800 [Rpm] - spindle power : 4 [kW] - min/max grinding wheel diameter : 165 - 400 [mm] - grinding wheel width normal 50 [mm] bigger 80 [mm] - grinding wheel boring normal 76 [mm] for grinding wheel diameter 400 127 [mm] - weight : about 2600 [kg]
