SPECIFICATION | Controller： OSP-P300M
Table size: 2,200×850 mm
Max load capacity: 2,500 kg
Travel : X： 2,050 Y： 850 Z： 750 mm
Distance between table and spindle nose : 200～950 mm
Spindle taper : BBT50 (BIG plus)
Spindle speed : 50～12,000 rpm
ATC : 36 stations
Required Floor space : 5,200 × 4,205 mm
Machine height : 3,160 mm
Machine weight : 15,000 kg
≪Options≫
Absolute Scale Detector (X, Y, Z)
Spindle center through coolant 1.5Mpa
Chip Air Blower
Pull stud bolt shape: MAS2
In-Machine Coil Conveyor
Lift-Up Chip Conveyor, Tilt-Type Chip Bucket
Spindle Head Cooling Unit, Oil Controller
Mist Collector
Coolant System, Coolant Separation Tank |
|---|
