SPECIFICATION | Control unit: OSP‑P300MA‑H
Table size: φ400 mm
Maximum workpiece dimensions: φ500 × H400 mm
Maximum loading capacity: 300 kg
Travel (X, Y, Z) : 740 x 460 x 460 mm
B : +90～ –120° C : 360°
Distance from spindle nose to table top: 120～580 mm
Spindle taper: BBT40 (BIG‑PLUS)
Spindle speed: 50～15,000 rpm
Tool storage capacity: 64 tools
Required floor space: 2,399 × 3,444 mm
Machine height: 2,950 mm
Machine weight: 9,700 kg
Lift‑up chip conveyor, drum‑through type (rear discharge)
X/Y/Z axis absolute scale feedback system
Tool Breakage Detection and Automatic Tool Length Measurement
Touch Probe for Workpiece Measurement (Renishaw)
Spindle Center Through-Coolant: 1.5 MPa
IMAP conversational programming
Mist collector
Shower cleaning system (including nozzle mounting tools)
Work washing gun (drum‑through type) |
|---|
