MAKINO

a81-5XR

Controller : Professional 5 (FANUC 310is) Table Size: 630 × 630 mm (2‑ pallets)　　Index.Accuracy: 0.0001° Workpiece Weight: 1,200 kg / per pallet Maximum Workpiece Size (Diameter × Height): 1,000 × 1,300 mm Distance from Pallet Top Surface to Spindle Center: 80～800 mm Distance from Pallet Center to Spindle Nose: 50～1070 mm Distance from Spindle Center to Column Front: 1,050 mm Travel X: 900　Y: 800　Z: 1,020 mm　C: 360°_(One side) 　 B: One side 360°/ One side 210° ( -60°～+150°) Spindle Taper: BBT50　（BIGプラス） Spindle Speed: 20～10,000 rpm ATC Capacity: 186 tools Required Floor Space: 4,511 × 6,830 mm (including ATC) Machine Height: 3,342 mm Machine Weight: 16,000 kg Vertical NC rotary table specification (C-axis), single pallet Matsumoto MDVi503 0500 T-slot pallet Simultaneous 5‑axis control Moiré scale X / Y / Z (0.1 μm) B-axis: NC rotary table (0.0001° encoder) C-axis: Rotary work table (inductosyn scale) Internal center trough conveyor (hinged type) Rear‑discharge two‑stage chip conveyor BDW1030 Oil skimmer (for water‑soluble coolant, belt type) Through‑spindle coolant (7 MPa) and air (standard) Cutting temperature controller Air blow unit Mist collector Automatic tool length measurement device (special specification) Automatic workpiece measurement system (Marposs) Pallet seating confirmation function Program memory capacity: 1,280 m Registered program capacity: 1,000 programs Tool offset memory type C Coordinate rotation Additional custom macro common variables: total 600 Super GI.4 control (for 5XR) (X, Y, Z, B, C axes) Tool tip point control High‑speed Smooth TCP 3D tool radius compensation Workpiece setting function

Expected to arrive in September
