OKUMA

MULTUS-4000U

Control unit : OSP-P500S Swing over saddle (Upper/ Lower turret): φ650 mm/φ320 mm Max. machining dia.: Upper φ650 mm/ Lower φ320 mm Maximum machining length: 1,500 mm Maximum workpiece weight (including chuck) Cantilever support: 118–335 kg Between centers: 620 kg Travel Upper tool turret: 　　　 X : 695 Y : 300 mm (±150) Z : 1,600 mm 　　　 B‑axis: 30°–210° (indexing 0.001°) Travel Lower tool turret: 　　　 X : 235 Z : 1,524 mm 　　　 C‑axis: 360° (indexing 0.0001°) W: 1,524 mm 　　　 Spindle speed : 45～4,200 rpm Spindle tip : JIS A2-８ Main spindle through‑hole diameter: φ91 mm Opposed spindle speed: 38～3,800 rpm Opposed spindle nose: JIS A2‑8 Opposed spindle through‑hole diameter: φ80 mm 　　　 Turret type: Upper: H1 (shared for L/M)　　Lower: V12 　　　 Tool storage capacity: 40 tools Tool spindle speed (upper): 50～12,000 rpm Tooling interface: HSK‑A63 Required floor space : 5,425 × 3,082 mm Height : 3,030 mm Net weight : 18,000 kg ≪Options≫　　　　　 Main spindle: D230 2J COMP (Teikoku Chuck) 　　　 Opposed spindle: FD‑215 (Teikoku Chuck) Hydraulic cylinders: Main / Opposed – SIN‑L125 (SMW) SMW special steady rest (mounted on lower turret) Coolant circuit: Upper turret through‑spindle, low pressure 　　　 Tool turret air blow: 　　Upper: shared with HI coolant (through during L/M rotation/ outer circumference) 　　Lower: combined with coolant nozzle 　　　 In‑machine work measurement: RMP60 (Renishaw) 　　　 Tool setter Work support rest (mounted on lower turret) 　　　 Easy conversational advice function Cycle tapping DNC‑TI Helical cutting Inclined machining mode Chip conveyor (front right discharge)
