OKUMA

VTM-200YB

Maximum swing: φ2,400 mm Maximum machining diameter: φ2,000 mm Maximum machining length: 1,400 mm Maximum workpiece weight (including chuck weight): 7,000 kg 　　　 Cantilever support : 110 kg/ Double center support : 500 kg 　　　 Travel X: 1,600 Y: ±800 Z: 1,400 mm 　　　 B: 120° (-15° to 105°) 　　　 C: 0.001 index B-axis spindle NC indexing (0.001° index, 5° index combined) 　　　 Chuck rotation speed: L (low speed): 4 ～200 rpm H (high speed): 6 ～ 400 rpm 　　　 Tool rest type : H1 (1 for L (turning) and M (rotating tool)) Spindle rotation speed (M-axis): 4,000 rpm Tooling: BBT50 (BIG PLUS) Magazine tool storage capacity: 36 tools Tool post type: ATC single tool Required floor space: 6,193 x 7,325 mm Height: 4,745 mm Machine weight: 35,000 kg (excluding chuck) 　　　 Controlled Axes: 5 axes (X, Y, Z, B, C) (3 axes controlled simultaneously, excluding B) 　　 φ2,000 mm 4-jaw indented chuck (jaw lock) B-axis angled indexing for turning (indexing every 5°) M-axis spindle center through coolant: 1.5 Mpa X, Y, Z, and B-axis scale feedback Automatic cutting edge measurement (automatic ATS) by Renishaw 　　　 Touch probe for workpiece measurement by Renishaw Chip conveyor (hinge type) Automatic door for workpiece removal 　　　 Tape storage capacity: 1280 m Chamfering, corner radius 　　　 Helical interpolation 　　　 Data server: 1 GB Spare M-codes: 4
