Vertical Mill

Access: 266

Print PhotosPrint FAX PAPER

STOCK CODE

20404031
CONTACT SELLER

This product is sold by
Shinmeiwa Kiko Co.,Ltd.

By PHONEBy EMAIL

MACHINE ID

17195

MANUFACTURER

MATSUURA MACHINERY

MODEL

VC-1800

YEAR

1976

PRICE

SPECIFICATION

◆Size of table work surface: 280＊1250mm ◆Table movement XYZ: 600＊300＊400mm ◆Number of left and right feed speed changes: 18 steps (dial change) ◆Left and right feed speed: 18-985mm/min ◆Spindle end: #40 ◆Spindle speed change: stepless ◆Spindle rotation speed: 85-3600rpm ◆Quill vertical movement amount: 1225mm ◆Quill automatic feed speed: 0.04, 0.08, 0.16 (3 steps) ◆Spindle head rotation speed: 55° left and right each ◆Spindle motor: 3.3㏋ ◆Feeding motor: 400W 4/8P ◆Cutting oil electric motor: 80W ◆Ram travel amount: 400mm ◆Weight: 2000kg ◆Vertical fast forward motor: 400W 4P ◆Lubricating oil device: automatic lubrication ・Vise mouth width: 150mm ✤If there is a discrepancy between the specifications and the actual product, priority will be given to the actual product.

LINK URL

https://k-smk.co.jp/en/machines/20404031/

LOCATION

Mie

LOCATION DETAIL

SELLER COMPANY

Shinmeiwa Kiko Co.,Ltd

SELLER PROFILE

Shinmeiwa Kiko Co.,Ltd

See Product Inventory of this company＞

ADDRESS

3-5, Higashi Mochibukucho Yokkaichi City, Mie-pref, Mie, Japan, 510-8011

CEO NAME

CONTACT PERSON

Mr.Hashimoto / Ms.Fujio / Ms.Tsuji / Ms.Matsuzaki（Chinese）

TEL1

81-59-361-5505

TEL2

CELLPHONE

FAX

81-59-364-8737

BUSINESS HOURS

HOLIDAY

COMPANY DESCRIPTION

New & Used Machine tool,Press, Tools

INQIRY FORMContact By EmailMACHINE SPECIALTY

Machine Tools,Measuring / Testing,Presses,Sheet Metal

SITE URL

https://k-smk.co.jp/en/

COMPANY TYPE

Used Machine Dealer

{{ contactModal.id }}{{ contactModal.companyname }}{{ contactModal.title }}{{ contactModal.stockCode }}{{ contactModal.telephone }}{{ contactModal.inCharge }}
SOLD OUT
prevNext
Print PhotosSee More Details
