PEDDINGHAUS

FBD 1500

Equipped With: Fagor CNC Control (Updated) Three Drill Heads OXY Fuel Cutting Plasma Torch Power In-Feed Conveyor: ...... 20' Exit Conveyor: ............... 10' Dust Collector Maximum Plate Width: ......... 60" Minimum Plate Width: ......... 2" Maximum Plate Thickness: ..... 1.5" Minimum Plate Thickness: ..... 1/4" Maximum Length of Piece Part:. 28' Minimum Length of Piece Part: 36" Minimum Plate Drop Off: ...... 10" Passline: .................... 40" Maximum Work Piece Weight: ... 8,250 Lbs. Maximum Velocity X-Axis: ..... 600" Maximum Velocity Y-Axis: 600" Number of Drills: ...... 3 Maximum Drill Size: .... 2" Minimum Drill Size: .... 3/8" Power Per Spindle: .... 15 H.P Spindle Travel: ........ 11-13/16" Three Spindle Drill Specs: Spindle 1 = "Med" Speed: 75-757 RPM <1/2 Spindle 2 = "Slow" Speed: 62-623 RPM >5/8 Spindle 3 = "Fast" Speed: 90-907 RPM <3/8 100 AMP Consumable Specs: Material Thickness Min-Max: 1/8" 3/16" 1/4", 5/16" 3/8" 1/2" 5/8" 3/4" 200 AMP Consumable Specs: Material Thickness Min-Max: 1/4" 5/16" 3/8" 1/2" 5/8" 3/4" 7/8" 1" 1-1/4" 1-1/2" 1-34/" 2" Weight of Machine: 22,000 Lbs. Approximate
